Statistics Pipeline Modules Documentation¶

This directory contains comprehensive documentation for all modules in the Ensembl genes statistics pipeline.

Module Overview¶

The statistics pipeline consists of 13 modules organized into functional categories:

Data Retrieval Modules¶

1. fetch-genome - Retrieves genome sequences from Ensembl core databases
2. fetch-proteins - Extracts protein translations from Ensembl databases

BUSCO Quality Assessment Modules¶

1. busco-dataset - Downloads appropriate BUSCO lineage datasets
2. busco-genome-lineage - Runs BUSCO assessment on genome sequences
3. busco-protein-lineage - Runs BUSCO assessment on protein translations
4. busco-core-metakeys - Patches BUSCO metadata into core databases

Orthology Analysis Modules¶

1. omamer-hog - Performs orthology inference using OMAmer
2. omark - Quality assessment of protein annotations using OMark

Statistics Generation Modules¶

1. run-statistics - Generates comprehensive annotation statistics
2. run-ensembl-meta - Generates core database metadata SQL files

Database Operations Modules¶

1. populate-db - Executes SQL files to populate databases
2. db-metadata - Manages database metadata and versioning

Data Cleanup Modules¶

1. cleaning - Removes intermediate files to save storage space

Pipeline Flow¶

The typical execution flow of the statistics pipeline:

1. Data Retrieval
   └─> FETCH_GENOME
   └─> FETCH_PROTEINS

2. Quality Assessment (Parallel)
   ├─> BUSCO_DATASET
   │   ├─> BUSCO_GENOME_LINEAGE
   │   └─> BUSCO_PROTEIN_LINEAGE
   │       └─> BUSCO_CORE_METAKEYS
   │
   └─> OMAMER_HOG
       └─> OMARK

3. Statistics Generation
   ├─> RUN_STATISTICS
   └─> RUN_ENSEMBL_META

4. Database Population
   └─> POPULATE_DB

5. Metadata Management
   └─> DB_METADATA

6. Cleanup
   └─> CLEANING

Module Categories by Function¶

Quality Control¶

• BUSCO Genome Lineage: Assesses genome completeness
• BUSCO Protein Lineage: Assesses proteome completeness
• OMark: Validates annotation consistency using orthology

Statistics & Metrics¶

• Run Statistics: Computes gene/transcript/protein counts by biotype
• Run Ensembl Meta: Generates schema and species metadata

Database Management¶

• BUSCO Core Metakeys: Inserts BUSCO metrics into database
• Populate DB: Executes SQL files for statistics insertion
• DB Metadata: Manages database versioning and tracking

Resource Management¶

• Cleaning: Removes cached intermediate files

Key Dependencies¶

External Tools¶

• BUSCO (v5+): Genome/proteome completeness assessment
• OMAmer: Orthology inference
• OMark: Annotation quality assessment

Ensembl Dependencies¶

• Ensembl Perl API: Database access and manipulation
• Ensembl Python libraries: Metadata generation
• Ensembl scripts: Statistics computation and data extraction

Databases¶

• Ensembl Core Database: Primary target for statistics
• BUSCO Lineage Datasets: Reference for completeness assessment
• OMAmer HOG Database: Reference for orthology inference

Common Parameters¶

Most modules use these common parameters:

Database Connection¶

• params.host: Database host
• params.port: Database port
• params.user: Database username (when required)
• params.password: Database password (when required)

Paths¶

• params.outdir: Output directory for published results
• params.cacheDir: Cache directory for intermediate files
• params.enscode: Path to Ensembl code repository

Execution Control¶

• params.files_latency: Delay after file operations (file system sync)
• maxForks: Limit parallel process execution

Caching Strategy¶

Several modules use storeDir for persistent caching:

• fetch-genome: Caches genome sequences by GCA
• fetch-proteins: Caches protein translations by GCA
• busco-dataset: Caches BUSCO datasets by lineage
• omamer-hog: Caches orthology assignments by GCA

This strategy reduces redundant computations and database queries when processing the same genomes multiple times.

Conditional Execution¶

Some modules execute conditionally based on parameters:

• BUSCO_CORE_METAKEYS: params.apply_busco_metakeys
• POPULATE_DB: params.apply_ensembl_stats OR params.apply_ensembl_beta_metakeys
• CLEANING: params.clean AND params.clean_work_dir

Output Structure¶

Results are typically organized by genome assembly accession:

${params.outdir}/
└── ${meta.gca}/
    ├── busco_genome_lineage/
    ├── busco_protein_lineage/
    ├── omark_output/
    ├── core_statistics/
    │   └── *.sql
    └── versions.yml

Metadata Requirements¶

All modules expect metadata maps with these common fields: - gca: Genome assembly accession (GCA_XXXXXXXXX.X) - dbname: Ensembl core database name - production_name: Species production name - species_id: Species identifier (for database operations)

Documentation Format¶

Each module documentation includes: - Overview: Purpose and functionality - Process Details: Labels, tags, directives - Inputs: Expected input channels and metadata - Outputs: Generated output channels - Parameters: Required and optional configuration - Script Details: What the process does - Dependencies: External tools and libraries - Notes: Important considerations and best practices

Version Tracking¶

All modules generate versions.yml files that track: - Tool versions (BUSCO, OMAmer, OMark, etc.) - Language versions (Python, Perl) - Database client versions (MySQL)

These version files support reproducibility and troubleshooting.

For More Information¶

• See individual module documentation files for detailed information
• Refer to the main pipeline documentation for workflow orchestration
• Check Ensembl documentation for database schema details
• Consult tool-specific documentation (BUSCO, OMAmer, OMark) for advanced usage
